DIN Cast Iron Flanged ANGLE Valve .ANGLE CHECK PN6/10/16/25/40/64 Face to face as per DIN3202F1 as per DIN2533

DIN CAST IRON ANGLE VALVE & GLOBE CHECK VALVE,PN10/PN16
GREAT MARINE Face to face as per DIN3202 F1
Flange as per DIN2533 PN10/PN16
Medium: Water, Steam, Oil
Working Temperature: ≤ 200℃

Max@Greatmarinevalve.com

No.	Component	Material
1	Body	Cast Iron
2	Seat ring	Staninless steel
3	Disc	Staninless steel
4	Stem	Staninless steel

Size	L	D	D1	D2	b	f	Z-Φd	Do	H
15	130	95	65	47	14	2	4-14	80	170
20	150	105	75	58	16	2	4-14	80	170
25	160	115	85	68	16	2	4-14	100	190
32	180	140	100	78	18	2	4-18	120	210
40	200	150	110	88	18	3	4-18	120	220
50	230	165	125	102	20	3	4-18	140	235
65	290	185	145	122	20	3	4-18	160	275
80	310	200	160	138	22	3	8-18	240	335
100	350	220	180	158	24	3	8-18	240	375
125	400	250	210	188	26	3	8-18	280	425
150	480	285	240	212	26	3	8-23	320	490
200	600	340	295	268	30	3	12-23	360	620

No.	Component	Material
1	Body	Cast Iron
2	Seat ring	Staninless steel
3	Disc	Staninless steel
4	Stem	Staninless steel

Size	L	D	D1	D2	b	f	Z-Φd	Do	H
15	90	95	65	47	14	2	4-14	80	260
20	95	105	75	58	16	2	4-14	80	280
25	100	115	85	68	16	2	4-14	100	290
32	105	140	100	78	18	2	4-18	120	315
40	115	150	110	88	18	3	4-18	120	345
50	125	165	125	102	20	3	4-18	140	370
65	145	185	145	122	20	3	4-18	160	415
80	155	200	160	138	22	3	8-18	240	480
100	175	220	180	158	24	3	8-18	240	545
125	200	250	210	188	26	3	8-18	280	620
150	225	285	240	212	26	3	8-23	320	700
200	275	340	295	268	30	3	12-23	360	845
250	325	405	355	320	32	3	12-27	400	1025

1117-) IMPA 755290 Angle Valve Din Cast Iron Flanged PN10/16 #269 300mm

1118-) IMPA 755289 Angle Valve Din Cast Iron Flanged PN10/16 #269 250mm

1119-) IMPA 755288 Angle Valve Din Cast Iron Flanged PN10/16 #269 200mm

1120-) IMPA 755287 Angle Valve Din Cast Iron Flanged PN10/16 #269 175mm

1121-) IMPA 755286 Angle Valve Din Cast Iron Flanged PN10/16 #269 150mm

1122-) IMPA 755285 Angle Valve Din Cast Iron Flanged PN10/16 #269 125mm

1123-) IMPA 755284 Angle Valve Din Cast Iron Flanged PN10/16 #269 100mm

1124-) IMPA 755283 Angle Valve Din Cast Iron Flanged PN10/16 #269 80mm

1125-) IMPA 755282 Angle Valve Din Cast Iron Flanged PN10/16 #269 65mm

1126-) IMPA 755281 Angle Valve Din Cast Iron Flanged PN10/16 #269 50mm

1127-) IMPA 755280 Angle Valve Din Cast Iron Flanged PN10/16 #269 40mm

1128-) IMPA 755279 Angle Valve Din Cast Iron Flanged PN10/16 #269 32mm

1129-) IMPA 755278 Angle Valve Din Cast Iron Flanged PN10/16 #269 25mm

1130-) IMPA 755277 Angle Valve Din Cast Iron Flanged PN10/16 #269 20mm

1131-) IMPA 755276 Angle Valve Din Cast Iron Flanged PN10/16 #269 15mm

1147-) IMPA 755260 Angle Valve Din Cast Iron Flanged PN10/16 #242 300mm

1148-) IMPA 755259 Angle Valve Din Cast Iron Flanged PN10/16 #242 250mm

1149-) IMPA 755258 Angle Valve Din Cast Iron Flanged PN10/16 #242 200mm

1150-) IMPA 755257 Angle Valve Din Cast Iron Flanged PN10/16 #242 175mm

1151-) IMPA 755256 Angle Valve Din Cast Iron Flanged PN10/16 #242 150mm

1152-) IMPA 755255 Angle Valve Din Cast Iron Flanged PN10/16 #242 125mm

1153-) IMPA 755254 Angle Valve Din Cast Iron Flanged PN10/16 #242 100mm

1154-) IMPA 755253 Angle Valve Din Cast Iron Flanged PN10/16 #242 80mm

1155-) IMPA 755252 Angle Valve Din Cast Iron Flanged PN10/16 #242 65mm

1156-) IMPA 755251 Angle Valve Din Cast Iron Flanged PN10/16 #242 50mm

1157-) IMPA 755250 Angle Valve Din Cast Iron Flanged PN10/16 #242 40mm

1158-) IMPA 755249 Angle Valve Din Cast Iron Flanged PN10/16 #242 32mm

1159-) IMPA 755248 Angle Valve Din Cast Iron Flanged PN10/16 #242 25mm

1160-) IMPA 755247 Angle Valve Din Cast Iron Flanged PN10/16 #242 20mm

1161-) IMPA 755246 Angle Valve Din Cast Iron Flanged PN10/16 #242 15mm
